Side Tilt Carriage - There are 4 sizings of hook type fork carriages rated by the fork carriage lifting capacity. Hook type tine carriages have been consistent.
The carriage bar spacing for Class 1 is about thirteen inches and the Class 1 carriage is rated to hold cargo up to 2000lbs. The Class 2 carriage is rated to hold loads up to 5,500lbs with carriage bar spacing of sixteen inches. Class III carriages are rated for loads as much as 10,000 lbs. The carriage bar spacing for this class is 20 inches. Class IV carriages are rated for cargo as much as 15,500 lbs. The carriage bar spacing for this capacity is 25 inches.
The carriages for pin type blades may be different depending on the maker. Pin mounted forks can vary by the amount of offset between the blade eye and the blade. Carriage capacity will be determined by the carriage pin size and by the fork size.
